Navgraha Steel & Engg Company offers Stainless Steel bars of superior quality. These SS 316 Bars are the best choice for several corrosive applications and strength requirements. Also, it is enhanced to hardness with harsh corrosion resistivity. These Bars are largely available in several specifications and standards. Its ductility is raised with other qualities like higher tensile strength, yield strength with less elongation, and minimum thermal expansion. These bars are easily formed in several shapes like rectangular, block, rods, threaded, billet form. Our bars are long-lasting with better electrical and thermal conductivity. It requires less maintenance and shows excellent strength and workability.
Stainless Steel SS 316 Bars are formed with excellent material of grade SS 316 are enhanced by Molybdenum. These are implemented for better mechanical strength and cover several corrosion effects. The annealing process is the hardening of these bars without affecting efficiency. Thus these bars are more malleable and more rigid than other grades bars. We offer various forms, including either or both ends with bevel, threaded end, and several other specifications. These bars are finely finished with different techniques.
SS 316 Wire are prevented to rust and cavity with excellent corrosion resistance. It is effective in surroundings containing acids, water, salt, and seawater. At elevated temperatures, these bars are unaffected and prolong stronger.
Stainless Steel SS 316 Characteristics:
SS 316L Bars are selected for:
SS 316, 316L Bars employed in:
SS 316 Bars are easily used for stress introducing excellent stress cracking strength, and heat resistance is more significant for a wide range, including cryogenic temperatures. Stainless Steel SS 316L Bars contain low carbon that is effective in various corrosions, and the best suitable to resist sensitization occurred due to grain boundary carbide precipitations. Additionally, it is trouble-free to form as low carbon improves the formability and flexibility of the bars. It also eliminates the annealing requirement after welding.
Specifications | ASTM A276, A580 / ASME SA276, SA580 |
Standards | DIN, ASTM, ASME, BS and all International Standards |
Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
Diameter | Outside Diameter in the range of 4mm to 500mm |
Width | 1m to 48″ |
Hex Bars | 18mm – 57mm (11/16″ to 2-3/4″) |
Square Bars | 18mm – 47mm (11/16″ to 1-3/4″) |
Flat Bars | 1/2” to 10” in the thickness range of 2mm to 150mm |
Wire Length | Max 12000 mm |
Wire Mesh Length | 30m to 100″ |
Wire Diameter | 5.5 – 400 mm |
Length | 1 to 6 Meters, Custom Cut Lengths |
Form | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging, Wire Mesh, Hexagonal Wiremesh, Welding Wiremesh, Netting Wiremesh, Woven Wiremesh, Spring Steel wire mesh, Square Wiremesh Etc |
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17-11-02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17-11-02 / Z3CND18-14-03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.89 min |
Grades | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
SS 316 / 316L | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
